Benchmarks

TL;DR

All rows below come from one full shadowtree benchmark run (four proxies) on 2026-05-03 (preset=smoke). They are useful for relative comparison on this machine and preset, not for universal rankings.

• Reused HTTP/1.1: Nginx ~72k req/s; Traefik ~42.5k; GoDoxy ~41.4k; Caddy ~34.6k.
• Reused HTTP/2 (h2load -m16): Nginx ~85k req/s; GoDoxy ~39.4k; Caddy ~31.3k; Traefik ~19.6k — this run reported 0 h2load failures and 0 HTTP 5xx for every proxy in the summary lines.
• Reused HTTP/3 (h3bench): Nginx ~31.5k req/s; GoDoxy ~21.0k; Traefik ~17.5k; Caddy ~15.9k (all Failed: 0 in the h3bench summaries).
• Fresh connection tests used 2000 requests with 32 concurrent connections (h2load --h1 -m1 / h2load -m1 / h3bench -m1). Every proxy completed 2000 / 2000 for HTTP/1.1, HTTP/2, and HTTP/3 in this run.
• HTTP/1.1 cleartext on ports 8080-8083 was disabled (h1c=false); enable with h1c=true for plaintext H1 comparable to TLS H1.

Benchmark setup

Source code:

• dev.compose.yml
• .shadowtree/benchmark.toml
• cmd/bench_server/main.go

Run all benchmark modes:

shadowtree benchmark

From the repo root, shadowtree help benchmark prints the full typed argument list. Common invocations:

# Presets: smoke (default), stable, stress
shadowtree benchmark preset=stable
shadowtree benchmark preset=smoke
shadowtree benchmark preset=stress

# Protocol toggles (defaults: h1/h2/h3 on, h1c off)
shadowtree benchmark h1=false
shadowtree benchmark h2=false
shadowtree benchmark h3=false
shadowtree benchmark h1c=true           # cleartext HTTP/1.1 on :8080-:8083
shadowtree benchmark h1c=false

# Connection mode (default: both)
shadowtree benchmark connection_mode=reused
shadowtree benchmark connection_mode=fresh
shadowtree benchmark connection_mode=both

# Combine typed args
shadowtree benchmark preset=stable h1=false h3=false

Selected typed arguments (defaults come from the active preset unless you override):

preset=smoke|stable|stress
h1=true|false h2=true|false h3=true|false h1c=true|false
connection_mode=both|reused|fresh
target=GoDoxy|Traefik|Caddy|Nginx    # case-insensitive; omit for all four

duration=10s                         # whole-second duration
threads=4
connections=32
streams=16                           # concurrent streams per H2/H3 connection
requests=2000                        # requests per protocol in fresh mode
fresh_connections=32                 # concurrent connections for fresh runs; 0 uses connections

h2load_warm_up_time=3s               # reused-mode warm-up; 0 disables
h2load_duration=0s                   # whole-second h2load duration; 0s derives from duration
h3_tool=auto|h2load|h3bench
latency_samples=5 runs=1 repeat_delay=1

upload_body_bytes=262144

compose_file=dev.compose.yml
compose_manage=true|false compose_cleanup=true|false compose_recreate=true|false

host=bench.domain.com                # hostname for SNI and bench URLs

Built-in Shadowtree presets:

All three presets use 4 h2load threads and set a non-zero warm-up before reused throughput (smoke 3s, stable/stress 5s). When runs is greater than 1, the recipe repeats each throughput benchmark and prints a median / coefficient-of-variation summary (stable, stress, or your own runs). Override preset defaults with the typed args above.

What gets tested

The benchmark uses a Go upstream server that returns a 4096-byte response body. The recipe starts four reverse proxies and tests each through TLS listeners:

The benchmark preserves bench.domain.com as SNI and :authority, then connects to loopback with:

• h2load --connect-to=127.0.0.1:<port> for throughput tests
• curl --resolve for probe-style checks

HTTP/1.1 and HTTP/2 run over HTTPS. HTTP/2 is real TLS/ALPN H2, not h2c. The compose stack also exposes cleartext HTTP on 8080-8083 (http://bench.domain.com:<port>/) for optional HTTP/1.1 plaintext baseline runs (h1c=true); when enabled, the recipe exercises the same h2load --h1 -m1 scenarios without TLS. The stack also exposes UDP listeners for HTTP/3.

HTTP/3 defaults to h3_tool=auto: use h2load --h3 when available, otherwise build and run the bundled cmd/h3bench client. With h3bench, reused throughput uses a fixed-duration run; fresh one-request-per-connection uses h3bench -m1 (as in this capture). Force h3bench explicitly with:

shadowtree benchmark h3_tool=h3bench

Disable HTTP/3 with either:

shadowtree benchmark h3=false

Run details

HTTP/1.1 cleartext baseline

Cleartext HTTP/1.1 reuses the same h2load reused- and fresh-connection settings as TLS H1, but targets http://bench.domain.com:808x/ with --connect-to to loopback. This run did not enable it, so there are no plaintext req/s or latency rows to publish here. Re-run with:

shadowtree benchmark h1c=true

Console markers look like [HTTP/1.1 cleartext reused] h2load --h1 -m1 and [HTTP/1.1 cleartext fresh].

Reused TLS throughput

Persistent/reused connection tests show steady-state proxy throughput after connection setup.

• H1/H2: h2load; throughput in req/s; transfer in MB/s; latency is mean time for request.
• H3: h3bench; transfer in MiB/s; latency columns are percentiles plus average.
• Done: completed requests in the timed window (includes warm-up / elapsed semantics from the recipe).
• Fail / 5xx: h2load failures and HTTP 5xx responses.

Notes:

• Compare HTTP/3 only across HTTP/3 rows. h3bench and h2load report different latency and transfer metrics.
• HTTP/2 mean latency in the H1/H2 columns is h2load mean time for request; under multiplexed load it reflects concurrent scheduling, not single-request latency.
• h2load sometimes prints slightly different totals for “done/succeeded” and the HTTP/2 status codes: summary; the Fail and 5xx columns follow the explicit failed / 5xx fields from the tool output in this capture.

Fresh TLS throughput

Fresh connection tests use 2000 new connections with one request each (h2load --h1 -m1 for HTTP/1.1 and h2load -m1 for HTTP/2). HTTP/3 uses h3bench -m1` with the same 2000 requests / 32 connection settings. These numbers mostly reflect handshake, accept-loop, and short-lived QUIC or TCP connection behavior.

ok/fail shows succeeded requests versus failed attempts out of 2000 (all 2000 / 0 in this run).

Latency probes

Probe tests send five samples per route and protocol. Values below are mean TTFB in milliseconds. Bodies or first SSE chunks are about 4 KiB.

HTTP/3 probe latency includes QUIC setup behavior from the probe client. Treat those values as probe behavior, not pure steady-state HTTP/3 request latency.

SSE probe

SSE probes use /sse?count=3&interval_ms=150. Each result is five samples. The table shows ok/failed plus mean TTFB in milliseconds.

All SSE samples succeeded. Nginx had the lowest mean HTTP/1.1 SSE TTFB among the four in this run; GoDoxy was lowest on HTTP/3 SSE means in this snapshot.

WebSocket probe

Interpretation

• Reused HTTP/1.1: Nginx leads on req/s and mean time for request; Traefik edges GoDoxy slightly in this preset, with Caddy fourth.
• Reused HTTP/2: Nginx leads by a wide margin on aggregate req/s with low reported mean time for request; GoDoxy and Caddy follow, then Traefik. This smoke preset did not show the high failure rates sometimes seen at much higher client/stream counts; re-run with heavier settings before inferring stability limits.
• Reused HTTP/3: Nginx leads on req/s and transfer; GoDoxy, Traefik, and Caddy follow in that order here, with Caddy showing the highest p99 among the four.
• Fresh connections: Nginx leads on H1/H2/H3 instantaneous throughput in this harness; GoDoxy is second on HTTP/3 fresh, then Traefik and Caddy.
• Latency probes: H1/H2 stay in the low-millisecond band on most routes; a single slow QUIC dial or first sample can pull HTTP/3 /json averages up (visible on Caddy and GoDoxy in this run).
• Plaintext HTTP/1.1 was not exercised in this capture; set h1c=true to compare TLS vs cleartext H1 under the same recipe.

Resource usage

CONTAINER ID   NAME           CPU %     MEM USAGE / LIMIT     MEM %     NET I/O         BLOCK I/O   PIDS
c2437c342388   godoxy-proxy   0.89%     38.02MiB / 853.7MiB   4.45%     0B / 0B         0B / 0B     12
80ad84f07d31   socket-proxy   0.00%     2.156MiB / 853.7MiB   0.25%     15.7kB / 48kB   0B / 0B     5
